Eco-mode Speed
Per Charge(maximum）
Geared Hub Motor
Brakes
Sensor
Samsung/LG Battery
Chao Yang Fat Tire
Payload Capacity
The range can be affected by several factors like rider weight, incline, and pedal-assist levels, etc.
Elegance is in the Details
Designed to perfectly balance outstanding performance ultimate comfort, and timeless style. Explore as never before with ST202
Smart APP Control
The Smartravel ST202 Raptor, similar to Tesla EVs, comes equipped with a GPS tracker, allowing you to maintain real-time control of your e-bike using your cellphone
GPS Real-time positioning: view real-time positioning on the map.
Geo-fencing: set the terminal area on the app. When the terminal exceeds the presetlimit area, it will automatically send alarm information to your cellphone
Remote control: the motor can be controlled power off/on remotely
Abnormal alarm: the system realizes active alarm reminding for overspeed and displacement
Hostoric track playback: keep valid data within 7 days. App can filter riding track with date and time anddisplay it on the map.
Ride navigation: Launch ride navigation on the app
Real time riding data: View battery power, speed, current mileage, current riding time, and totalmileage
UPGRADED 1200W MOTOR
Fast Acceleration & Good Gradeability & Longer Lifespan
1200W Upgraded Brushless Geared Hub Motor Use the latest updated inner ring specialized in high temperature resistance and better heat dissipation, which can reduce the motor magnets’ attenuation speed to guarantee a longer life expectancy. The 1200W brushless gear hub motor can help you conquer even the most rugged terrain easily.
1200W
Geared Hub Motor
86 Nm
Max Torque
Imagine the FOC as the motor’s real-time brain. It assesses your riding conditions, promptly engaging the motor for peak performance. Additionally, it monitors scooter diagnostics—details hidden from you as the rider—and adapts its response based on your driving inputs
Long Range Expert
20AH High-performance Lithium-ion Battery
The Smartravel bike features cutting-edge battery technology, merging DMEGC advancements into a compact 3200mAh single cell. Unlike traditional 2500mAh nickel-cobalt-manganese cells, this 960Wh battery significantly enhances range, stability, and safety. With a single charge, you can cover up to 80KM using pure electric power or over 80 KM with pedal assist mode. Remarkably, even after 800 charges, the battery retains 80% of its original capacity
80 KM
Per Charge (maximum)
8.8 lb
Battery Weight
Ensuring the durability and efficiency of your ride through smart battery safeguards
Short Circuit Prevention
Over-load Prevention
Reverse Prevention
Wiring Protection
Over-current Prevention
Over-charging Over-discharging
Cell Balancing
PTC Chip
Temperature Control
1 – Much like Tesla, the travel distance can fluctuate based on variables like rider weight, terrain incline, and pedal-assist settings
CLEAR AT A GLANCE
Fast Acceleration & Good Gradeability & Longer Lifespan
The Color LCD display shows speed, mileage, gear level and power
USB Charging
Security Code
State of Riding
Fault Warning
Cycling Data
Function Set
Switch
Light ON/OFF
Info
Half twist throttle
Shimano gearbox
Bell
They feature excellent dual-shoulder suspension front forks andrear shocks for a more comfortable ride.
Front/rear turn signals Ensure safer riding on roads
Hydraulic Brakes
Hydraulic brakes deliver exceptional braking performance and long-lasting durability. With regular maintenance, you can expect consistent braking power for up to 5 years
Bright Headlight
The bright headlights ensuring safe driving for you, especially at night or in low-light conditions
Gain Extra Payload With 2X Thicker Frame
The ST202 features an upgraded 6061 Aluminum frame, twice as thick as conventional bike frames, and incorporates an integrated battery design. This sturdy frame can support weights of up to 400 lbs, all while ensuring the stability of the motor and battery. Riding the ST202 feels akin to maneuvering a tank off-road, offering a solid, safe, and reliable riding experience.
400 lb.
Payload Capacity
79 lb.
Weight
The e-bike features a removable built-in battery that is smartly designed to withstand dust, dirt, rain, and other environmental hazards. This ensures a longer battery life and a safer ride. The e-bike also looks more fashionable and modern, with a sleek and integrated battery that blends in with the frame. You don’t have to worry about thieves stealing your battery, as it is securely locked inside the e-bike.
The ChaoYang All-terrain Fat Tire
Chaoyang 20″x4.0″ fat tires offer robust grip and traction on rough terrain. Whether you’re navigating challenging landscapes or adverse weather, these tires ensure your safety and deliver a comfortable, smooth riding experience
Gravel Road
Sandy Ground
Mountain
Brick Road
Wetland
Snowy Road
Eco-mode Speed
Per Charge
(maximum）
Geared Hub Motor
Brakes
Sensor
Samsung/LG Battery
Kenda Fat Tire
Payload Capacity
The range can be affected by several factors like rider weight, incline, and pedal-assist levels, etc.
Elegance is in the Details
Designed to perfectly balance outstanding performance ultimate comfort, and timeless style. Explore as never before with ST202
Smart APP Control
The Smartravel ST202 Raptor, similar to Tesla EVs, comes equipped with a GPS tracker, allowing you to maintain real-time control of your e-bike using your cellphone
GPS Real-time positioning: view real-time positioning on the map.
Geo-fencing: set the terminal area on the app. When the terminal exceeds the presetlimit area, it will automatically send alarm information to your cellphone
Remote control: the motor can be controlled power off/on remotely
Abnormal alarm: the system realizes active alarm reminding for overspeed and displacement
Hostoric track playback: keep valid data within 7 days. App can filter riding track with date and time anddisplay it on the map.
Ride navigation: Launch ride navigation on the app
Real time riding data: View battery power, speed, current mileage, current riding time, and totalmileage
UPGRADED 1200W MOTOR
Fast Acceleration & Good Gradeability & Longer Lifespan
1200W Upgraded Brushless Geared Hub Motor Use the latest updated inner ring specialized in high temperature resistance and better heat dissipation, which can reduce the motor magnets’ attenuation speed to guarantee a longer life expectancy. The 1200W brushless gear hub motor can help you conquer even the most rugged terrain easily.
1200W
Geared Hub Motor
86 Nm
Max Torque
Imagine the FOC as the motor’s real-time brain. It assesses your riding conditions, promptly engaging the motor for peak performance. Additionally, it monitors Ebike diagnostics—details hidden from you as the rider—and adapts its response based on your driving inputs
LONG RANGE EXPERT
20AH High-performance Lithium-ion Battery
The Smartravel bike features cutting-edge battery technology, merging DMEGC advancements into a compact 3200mAh single cell. Unlike traditional 2500mAh nickel-cobalt-manganese cells, this 960Wh battery significantly enhances range, stability, and safety. With a single charge, you can cover up to 60KM using pure electric power or over 80 KM with pedal assist mode. Remarkably, even after 800 charges, the battery retains 80% of its original capacity
80 KM
Per Charge (maximum)
8.8 lb
Battery Weight
Ensuring the durability and efficiency of your ride through smart battery safeguards
Short Circuit Prevention
Over-load Prevention
Reverse Prevention
Wiring Protection
Over-current Prevention
Over-charging Over-discharging
Cell Balancing
PTC Chip
Temperature Control
1 – Much like Tesla, the travel distance can fluctuate based on variables like rider weight, terrain incline, and pedal-assist settings
Clear At A Glance
The Color LCD display shows speed, mileage, gear level and power
USB Charging
Security Code
State of Riding
Fault Warning
Cycling Data
Function Set
Switch
Light ON/OFF
Info
Headlight On/Off
Right/Left Turn Signal
Horm Activate
Half twist throttle
Shimano gearbox
Bell
They feature excellent dual-shoulder suspension front forks andrear shocks for a more comfortable ride.
Front/rear turn signals Ensure safer riding on roads
Hydraulic Brakes
Hydraulic brakes deliver exceptional braking performance and long-lasting durability. With regular maintenance, you can expect consistent braking power for up to 5 years
Bright Headlight
The bright headlights ensuring safe driving for you, especially at night or in low-light conditions
Gain Extra Payload With 2X Thicker Frame
The ST202 features an upgraded 6061 Aluminum frame, twice as thick as conventional bike frames, and incorporates an integrated battery design. This sturdy frame can support weights of up to 400 lbs, all while ensuring the stability of the motor and battery. Riding the ST202 feels akin to maneuvering a tank off-road, offering a solid, safe, and reliable riding experience.
400 lb.
Payload Capacity
79 lb.
Weight
The e-bike features a removable built-in battery that is smartly designed to withstand dust, dirt, rain, and other environmental hazards. This ensures a longer battery life and a safer ride. The e-bike also looks more fashionable and modern, with a sleek and integrated battery that blends in with the frame. You don’t have to worry about thieves stealing your battery, as it is securely locked inside the e-bike.
Live Electric, Ride Bold.
The ChaoYang All-terrain Fat Tire
Chaoyang 20″x4.0″ fat tires offer robust grip and traction on rough terrain. Whether you’re navigating challenging landscapes or adverse weather, these tires ensure your safety and deliver a comfortable, smooth riding experience
Gravel Road
Sandy Ground
Mountain
Brick Road
Wetland
Snowy Road
A – total length
70.8
B – handlebar height
48.8
C – handlebar length
29.1
D – wheelbase
47
E – wheel diameter
23.3
F – minimum seat height
33
G – maximum seat height
33
H – chain stay length
22.5
I – frame stack
31.9
K – effective top tube length
29.4
L – head tube length
6.7
M – head angle
66.8°
N – standover height
31.8
Frame
6061 Aluminum frame
Headset
Neco H114 28.6*44*30
Fork
KKE R150S coil spring fork compression | Rebound adjustable 140mm travel 15*150mm axle
Shock
EXA A5-RE 180*47mm
Front wheel
Rim: MD-147 20*4.0″”*36H*12G A/V | Spoke: 12G 171mm/173mm | Hub: MB016F-92-T 15*135MM 12G*36H
Rear wheel
Rim: MD-147 20*4.0″”*36H*12G A/V | Spoke: 12G 126mm/127mm Hub: 48v 1200w | Hub Motor
Tires
Chao Yang 20*4.0
Battery
Samsung/LG 48V 20Ah
Motor
1200W brushless gear motor
Display
Smartravel LCD Display
Throttle
Half-twiste throttle
Sensors
Speed sensor丨brake sensor
Crankset
44T BCD104 6061-T6 145mm
Freewheel
Shimano MF-TZ500-7 14-28T
Chain
KMC Z8.3 EPT 130L
Groupset
Shimano altus M310 7 speed
Front brake
Hydraulic brake
Rear brake
Hydraulic brake
Rotors
DengFengHua TR180-52 F:180mm R:180mm
Stem
3D forged alloy Ext:40mm
Handlebar
YC-B086 22.2*31.8*720mm
Seatpost
/
Saddle
Leather seat
Pedal
Aluminum pedal
Lights
48V LED light
Kickstand
Heavy-duty aluminum kickstand
Range
60-80 KM
Controller
48V/22A
Charger
US standard 3.0 A smart charger
Rider height
5’4″~6’3″
Weight
88 lb.
Max. system weight
330 lb.
1 – Zebra: Half twist throttle
Third party reviews
FAQs
The seat height is 33 inches.
Only simple installation is required, our ST202 electric bike is 90% assembled. All you need to do is drive into the fun blind box and secure the handlebars with a few screws.
The ST202 e-bike is equipped with a powerful LG 48V 20Ah battery that can be fully charged in only 5 hours and can travel as far as 60-80 KM on a single charge. Experience the thrill of the ride, conquer city streets, and embrace endless exploration.
Absolutely! When the battery runs out, the ST202 seamlessly transitions into a traditional bike with 0 to 5 levels of pedal assist. In power mode, the ST202 transforms into an electric bike, a racing bike, or even a motorcycle, enhancing your stability and handling while delivering an exhilarating off-road riding experience.
The battery can last for 60-80 KM and it only takes 5-6 hours to be fully charged.
Fun Functional and Pretty
The bike is sweet. Its zippy, can do 50kmph on the flats. My issues with the bike are very few, mostly to do with assembly. For example when connecting the turn signal wires, mine were neither different colours, nor marked which end was which. The internal connective wires look snappy and I initially connected them wrong, and I was afraid to disconnect and try again. It turned out fine.
My biggest issue is not with the bike itself, but the insuring nightmare its features create for Canadians. Because it goes over 32kmph but still has peddle assist, it doesn’t qualify for ANY type of vehicle insurance. Yet, because it goes so fast, if you are pulled over, you will be expected to have it insured and also have a motorcycle licence. This has been my bane for almost a month now, with all my struggle still to come. (because all my efforts have so far been for nothing)
TLDR: Great bike, Canadians be warned it is an insurance nightmare.
High Quality Ebike
This bike was a breeze to put together, however, unwrapping it took longer than the actual assembly did. So much tape and plastic wrap. The build quality is great, this bike looks like twice it’s actual price. The green color shown in the photo on the amazon listing is actually a bit brighter than the one I got. Not really a problem. It came with everything shown and everything is working as intended. EXCEPT FOR…
The smartravel app that they advertise with this bike. The app is a royal pain to use. You have to re-pair your bike to your phone bluetooth every single time the bike is turned off. Also, for some reason, it wants me to input a “GPS number” which I do not have. On top of that. The app only connects to the bike when the bike is actually powered on. This cannot be used to track your bike if it gets stolen, you must be within bluetooth range for it to connect to the bike. If the bike is off, you can’t connect. The app is more of.. a ride companion I guess? But other apps do the GPS job way better. The app isn’t worth installing or messing with. (I recommend just buying a GPS unit and hooking it up to the bike, it’s what I did, got to protect a nearly 2000 dollar investment, ya know?) I didn’t think the app being garbage was enough to knock a point off.
The bike however, is worth the money.
Very nice quality
This bike is very cool. Easy to put together. Heavy but nice to ride and well made. I can’t wait to take it off road. Works great on the street and grass areas so far
I am having trouble with the battery charging. I have contacted the manufacturer and waiting for a solution. I will ad to this review when the issue is fixed. The bike it is great
Exelente
Me facino,tiene buena velocidad ,la andube por 30 mintos y la batetia seguio full de carga.
Good all around ebike
I like it 🙂 this thing can climb hills and goes over 30 mph. It has good brakes, turn signals and a little storage compartment. It seems built to use mainly with the throttle only function based on my experience.
Some considerations:
It is very heavy, the seat does not adjust, and does take some getting used to – even just moving it around. I’ve done a lot of bolt tightening and some fit adjustments to dial it in. With over 200 actual miles on it I’m mostly satisfied. Expect to do a little adjusting and if necessary troubleshooting. They have ok customer service if necessary.
